DAMP 4.1500HD
The Alpha Acoustics DAMP 4.1500HD combines high power, refined sound, and advanced DSP in a compact 1U design. Delivering clean, controlled performance with FIR filtering, EQ, dynamics, and delay, it ensures precise system tuning for any application. With intuitive control via TCP/IP, USB, and a bright IPS display, plus built-in protection for reliable operation, the DAMP 4.1500HD is the perfect choice for auditoriums, houses of worship, touring, and professional installations.
- 4 × 1500W @ 8Ω, 2 x 4600W bridged @ 8Ω
- Class D amplification with PFC for high efficiency and stable performance.
- Built-in DSP with FIR support
- High resolution 96kHz/24-bit AD/DA converters for superior audio quality.
- Advanced protection – DSP limiter, thermal, DC, surge, short circuit, and power safety.
- 1U lightweight design with a color IPS display for easy monitoring.
Specialties of Amplifier
-
Channels
4
-
Power
4 x 2300W @4Ω
4 x 1500W @8Ω
2 x 4600W @8Ω -
Max input level
+17dBu
-
SNR
>104dB
-
THD
<1%
-
AD/DA
96kHz / 24-bit
Specifications
Electroacoustic
- No. of Channels4
- Impedance4Ω, 8Ω
- Power4 x 2300W @4Ω
4 x 1500W @8Ω
2 x 4600W @8Ω - Max input level+17dBu
- SNR>104dB
- THD<1%
- AD/DA96kHz / 24-bit
- DSP FunctionsMatrix, EQ, Dynamic EQ, Noise Gate, Delay, FIR, Compression, Limiter
- FIR1024 taps
- Audio Input ConnectorXLR
- Audio Output ConnectorSpeakon
- ControlTCP/IP, USB 2.0 (Type B)
- IndicatorsPower
- ProtectionDSP limiter; High temperature, DC, Short circuit, Back EMF, Peak current limiter; Surge current limiter; Startup delay; Over voltage/under voltage protection
Design
- DesignClass D with PFC
- ColorBlack
- EnclosureAluminum Alloy
- 1UYes
Physical
- Dimensions (W×D×H)483 x 550 x 44.5mm
- Net Weight10.3 Kg
- DisplayIPS display
Smarter Power.
Precise Control.
Deploy stadium-grade headroom with FIR precision—DAMP 4.1500HD brings massive power, rock-solid protection, and effortless control to your most demanding installs.
Request a Demo
